castor wheel, Ø 250 mm, cast iron wheel, 7025KG

Product description

Heavy duty swivel castor made of welded steel fork, plate fitting, cast iron wheel, conical ball bearing, Wheel-Ø 250mm, 7025KG

Wheel: cast iron wheel, with wheel core made of cast iron core, conical ball bearing,

Advantages: For very heavy transport on flat floors. Low rolling resistance. Relatively insensitive to notches and very wear-resistant.

Applications: Heavy material handling, heavy containers, automotive factories, petrochemical plants, heavy transport, ports, armed forces, aviation, bridge cranes, chemical plants.

Suitable substrate : Hard and flat such as tiles, cement and coatings.
Suitable environment : Dry and not permanently damp. With alcohol, glycol and many acids, bases and chemicals.

Quality & Service since 1946

Quality & Service since 1946

Our quality is creating an easier work-life for the user of the wheel.
Every user and application has different needs. Let us know how we can help you to become a satisfied customer.

More information

Wielen.nl is the range of the most popular wheels from our group of companies. Over two hundred fifty employees focus on manufacturing and developing high-quality wheels for the European market.

castor wheel, Ø 250 mm, cast iron wheel, 7025KG

Heavy duty swivel castor made of welded steel fork, plate fitting, cast iron wheel, conical ball bearing, Wheel-Ø 250mm, 7025KG

  • We want to make your work-life easier Tooltip Just tell us what you need
  • Fast delivery
  • 3D CAD Models
  • Engineering service

Product information

  • SKU 104876252
  • EAN 8718116095484

Specifications

  • Non marking tread No
  • Wheel diameter (mm) 250
  • Wheel witdh (mm) 102
  • Load capacity (kg) 7025
  • Overall height (mm) 400
  • Size of top plate (mm) 229x178
  • Topplate hole centres (mm) 178x127
  • Mounting hole diameter (mm) 20
  • Swivel offset (mm) 85
  • Swivel Radius 210
  • Bearing type cone ball bearing
  • Tread description Castors made of high-quality solid cast iron with convex running surface. Cast iron wheels are suitable for smooth floors and have a high load capacity and can withstand high temperatures.
  • Temperature -20 / +80°C
  • Castor wheel type Swivel castor
  • Fitting Plate mounting
  • Fork material Welded steel construction
  • Fork Extra-reinforced fork in steel-welded construction, galvanised, swivel head fitted with 2 tapered roller bearings and grease nipple.
  • Series 4.87
  • Tread cast iron wheel
