fixed castor, Ø 200mm, thermoplastic-tyre, 300KG

Product description

industrial fixed castor from pressed steel, top plate fitting, thermoplastic-tyre, ball bearing, Wheel-Ø 200mm, 300KG

thermoplastic rubber fixed castor

housing / bracket: pressed steel, bright zinc plated, blue passivated, top plate fitting
wheel: thermoplastic-tyre, with wheel centre from polypropylene, ball bearing, threadguards

Benefits: Versatile use with excellent rolling characteristics. Low noise and vibration damping, non-marking.

Applications: flight case, roll cage castor, trolleys for industrial handling, flight case , theatre & entertainment, blue elastic rubber

Suitable surface: Almost every surface: uneven surfaces such as pavers, damaged floors and obstacles such as thresholds.
Suitable environment: Dry and not permanently humid. For mild chemicals.

Quality & Service since 1946

Quality & Service since 1946

Our quality is creating an easier work-life for the user of the wheel.
Every user and application has different needs. Let us know how we can help you to become a satisfied customer.

More information

Wielen.nl is the range of the most popular wheels from our group of companies. Over two hundred fifty employees focus on manufacturing and developing high-quality wheels for the European market.

fixed castor, Ø 200mm, thermoplastic-tyre, 300KG

industrial fixed castor from pressed steel, top plate fitting, thermoplastic-tyre, ball bearing, Wheel-Ø 200mm, 300KG

Delivery within 4 business days possible

  • We want to make your work-life easier Tooltip Just tell us what you need
  • Fast delivery
  • 3D CAD Models
  • Engineering service
  • Estimated time: Delivery within 4 business days possible

Product information

  • SKU 246366201
  • EAN 8718116214847

Specifications

  • Non marking tread Yes
  • Wheel diameter (mm) 200
  • Wheel witdh (mm) 50
  • Load capacity (kg) 300
  • Overall height (mm) 235
  • Size of top plate (mm) 138x105
  • Topplate hole centres (mm) 105x80
  • Mounting hole diameter (mm) 11
  • Bearing type Ball bearing
  • Castor wheel type Fixed castor wheel
  • Fitting Plate mounting
  • Fork material Galvanised
  • Series 46.36S
  • Tread Solid rubber
