Fixed-wheel castor, Ø 100 mm, grey non-marking thermoplastic rubber tyre, 115KG

Product description

transport reinforced fork / housing fixed wheel made of pressed heavy sheet steel, plate mounting, gray non-marking thermoplastic rubber tire, Wheel Ø 100mm, 115KG

Wheel: grey non-marking TPR rubber tyre, with polypropylene wheel core, central ball bearing,

Advantages: The solid rubber tyres have a hardness of 72° Shore A and offer good driving characteristics, roll silently, are impact and shock resistant, corrosion resistant and have medium rolling resistance.

Applications: Versatile use for light transport in e.g. offices, warehouses, shops and institutions. Low-noise, impact-resistant and vibration-damping. Fixed castor for light applications. Less suitable for continuous, static use under maximum load.

Suitable surface: Flat or with minor unevenness. Non-striping tyre for use on ceramic tiles, linoleum, etc.
Suitable environment : Dry and not permanently damp. With light acids and bases.

Quality & Service since 1946

Quality & Service since 1946

Our quality is creating an easier work-life for the user of the wheel.
Every user and application has different needs. Let us know how we can help you to become a satisfied customer.

More information

Wielen.nl is the range of the most popular wheels from our group of companies. Over two hundred fifty employees focus on manufacturing and developing high-quality wheels for the European market.

Fixed-wheel castor, Ø 100 mm, grey non-marking thermoplastic rubber tyre, 115KG

transport reinforced fork / housing fixed wheel made of pressed heavy sheet steel, plate mounting, gray non-marking thermoplastic rubber tire, Wheel Ø 100mm, 115KG

Delivery within 4 business days possible

  • We want to make your work-life easier Tooltip Just tell us what you need
  • Fast delivery
  • 3D CAD Models
  • Engineering service
  • Estimated time: Delivery within 4 business days possible

Product information

  • SKU 284746101
  • EAN 8718116194774

Specifications

  • Non marking tread Yes
  • Wheel diameter (mm) 100
  • Load capacity (kg) 115
  • Overall height (mm) 128
  • Size of top plate (mm) 105x86
  • Topplate hole centres (mm) 80x60
  • Mounting hole diameter (mm) 9
  • Bearing type Central ball bearing
  • Hardness of tread 72° Shore A
  • Tread description Grey thermo (TPR) rubber
  • Temperature -20 / +60°C
  • Castor wheel type Fixed castor wheel
  • Fitting Plate mounting
  • Fork material Galvanised
  • Fork Fixed fork made of extra-thick pressed galvanised sheet steel
  • Series 84.74
  • Tread Solid rubber
