industrial polyurethane (PU) swivel castor
housing / bracket: pressed steel, double ball race in swivel head, bright zinc plated, blue passivated, top plate fitting
wheel: vulcanized polyurethane tread, with wheel centre from aluminium, precision ball bearing,
Benefits: For medium heavy transport on smooth floors. Low rolling resistance. Relatively insensitive to cut and tear propagation resistance and very durable. Non-marking, quiet operation. Smooth surface, hygienic.
Applications: Industrial carts, material handling in factories, waste containers, transport containers, metal working and chemical companies, medium load roll containers, tool trolleys, warehouse carts.
Suitable surface: Smooth and hard surface such as tiles, cement and coatings.
Suitable environment : Both indoors and outdoors. For alcohol, glycol, mineral oils and fats.
![](https://cdn.webshopapp.com/shops/352868/themes/183049/v/2130798/assets/logo.png?20231211163120)
![](https://cdn.webshopapp.com/shops/352868/themes/183049/v/2130798/assets/logo.png?20231211163120)
swivel castor, Ø 100mm, vulcanised polyurethane tread, 200KG
Product description
Quality & Service since 1946
Quality & Service since 1946
Our quality is creating an easier work-life for the user of the wheel.
Every user and application has different needs. Let us know how we can help you to become a satisfied customer.
Wielen.nl is the range of the most popular wheels from our group of companies. Over two hundred fifty employees focus on manufacturing and developing high-quality wheels for the European market.
Product information
- SKU 146416101
- EAN 8718116103554
Specifications
- Non marking tread Yes
- Wheel diameter (mm) 100
- Load capacity (kg) 200
- Overall height (mm) 128
- Size of top plate (mm) 105x80
- Topplate hole centres (mm) 80x60
- Plate hole (mm) 9
- Offset (mm) 37
- Swivel Radius 87.0
- Bearing type Ball bearing
- Hardness of tread 95° Shore A
- Temperature -20 / +60°C
- Castor wheel type Swivel castor
- Fitting Plate mounting
- Fork material Galvanised
- Fork Transport wheel Swivel fork with plate fitting made of pressed galvanised sheet steel. With central bolt double ball race in swivel head and dust seal
- Series 46.41
- Tread Polyurethane
