swivel castor, Ø 160 mm, elasticated rubber tyre, 300KG

Product description

transport reinforced fork / housing swivel wheel made of pressed heavy sheet steel, plate mounting, elastic rubber tire, precision ball bearing, Wheel Ø 125mm, 250KG

Wheel: elastic rubber tyre, with wheel core made of aluminium, precision ball bearing,

Advantages: Versatile use with excellent rolling properties. Low-noise and vibration damping.

Applications: Industrial trolleys, material handling in factories, waste containers, transport containers, metal and chemical plants, medium-load roll containers, tool trolleys, warehouse trolleys.

Suitable surfaces: Almost any surface. Uneven surfaces such as clinkers, damaged floors and near obstacles such as thresholds.
Suitable environment : Dry and not permanently damp. With alcohol, glycol and many acids, bases and chemicals.

Quality & Service since 1946

Quality & Service since 1946

Our quality is creating an easier work-life for the user of the wheel.
Every user and application has different needs. Let us know how we can help you to become a satisfied customer.

More information

Wielen.nl is the range of the most popular wheels from our group of companies. Over two hundred fifty employees focus on manufacturing and developing high-quality wheels for the European market.

swivel castor, Ø 160 mm, elasticated rubber tyre, 300KG

transport reinforced fork / housing swivel wheel made of pressed heavy sheet steel, plate mounting, elastic rubber tire, precision ball bearing, Wheel Ø 125mm, 250KG

within 3 working days

  • We want to make your work-life easier Tooltip Just tell us what you need
  • Fast delivery
  • 3D CAD Models
  • Engineering service
  • Estimated time: within 3 working days

Product information

  • SKU 174116160
  • EAN 8718116202134

Specifications

  • Non marking tread No
  • Wheel diameter (mm) 160
  • Wheelwitdh (mm) 50
  • Load capacity (kg) 300
  • Overall height (mm) 200
  • Size of top plate (mm) 135x110
  • Topplate hole centres (mm) 105x80
  • Plate hole (mm) 11
  • Offset (mm) 54
  • Swivel Radius 134
  • Bearing type precision ball bearing
  • Hardness of tread 70° Shore A
  • Tread description Elastic black vulcanised rubber tyre, with the shock-absorbing properties and low rolling resistance.
  • Temperature -20 / +80°C
  • Castor wheel type Swivel castor
  • Fitting Plate mounting
  • Fork material Galvanised
  • Series 74.11
  • Tread Solid rubber
