swivel castor with brake, Ø 125 mm, all-polyamide (PA6) wheel, 180KG

Product description

Stainless steel swivel castor with brake made of stainless steel (pressed), plate fitting, all-polyamide (PA6) wheel, stainless steel roller bearing, Wheel-Ø 125mm, 180KG

Wheel: all-polyamide (PA6) wheel, stainless steel roller bearing,

Advantages: The polyamide wheels have low rolling resistance, offer good handling on flat surfaces, are impact and shock resistant and resistant to corrosion.

Applications: Metal industry, chemical industry, trollies.

Suitable surfaces : Hard and flat such as tiles, cement and coatings.
Suitable environment : Dry and not permanently damp. With various chemicals and saturated steam.

Quality & Service since 1946

Quality & Service since 1946

Our quality is creating an easier work-life for the user of the wheel.
Every user and application has different needs. Let us know how we can help you to become a satisfied customer.

More information

Wielen.nl is the range of the most popular wheels from our group of companies. Over two hundred fifty employees focus on manufacturing and developing high-quality wheels for the European market.

swivel castor with brake, Ø 125 mm, all-polyamide (PA6) wheel, 180KG

Stainless steel swivel castor with brake made of stainless steel (pressed), plate fitting, all-polyamide (PA6) wheel, stainless steel roller bearing, Wheel-Ø 125mm, 180KG

  • We want to make your work-life easier Tooltip Just tell us what you need
  • Fast delivery
  • 3D CAD Models
  • Engineering service

Product information

  • SKU 196353123
  • EAN 8718116113232

Specifications

  • Non marking tread Yes
  • Wheel diameter (mm) 125
  • Wheel witdh (mm) 40
  • Load capacity (kg) 180
  • Overall height (mm) 155
  • Size of top plate (mm) 100x 85
  • Topplate hole centres (mm) 80x60
  • Mounting hole diameter (mm) 9
  • Swivel offset (mm) 44
  • Swivel Radius 106
  • Bearing type roller bearing stainless steel
  • Tread description Polyamide (PA6) wheels
  • Castor wheel type Swivel castor with brake
  • Fitting Plate mounting
  • Fork material Stainless steel AISI 304
  • Brake Brake blocks both the turning and swivelling movement of the wheel
  • Series 96.35
  • Tread fully nylon (PA6) wheel
