swivel fork with brake Ø200mm plate fitting 300KG
Product description
Quality & Service since 1946
Quality & Service since 1946
Our quality is creating an easier work-life for the user of the wheel.
Every user and application has different needs. Let us know how we can help you to become a satisfied customer.
Wielen.nl is the range of the most popular wheels from our group of companies. Over two hundred fifty employees focus on manufacturing and developing high-quality wheels for the European market.
Product information
- SKU 146008203
- EAN 8718116101215
Specifications
- Wheel diameter (mm) 200
- Load capacity (kg) 300
- Size of top plate (mm) 135x110
- Topplate hole centres (mm) 105x80
- Mounting hole diameter (mm) 11
- Swivel offset (mm) 60
- Fitting Plate mounting
- Fork material Galvanised
- Thickness top plate 4
- Fork type Swivel fork and brake
- Fork Swivel fork with plate fitting made of pressed galvanised sheet steel. With central bolt double ball race in swivel head and dust seal
- Brake Leading brake blocks both the swivelling and turning movement of the wheel. Made of galvanised pressed metal.
- Thickness fork legs 3
- Fork width (inner) 64
- Fork height 135
- Axle bore-Ø in fork legs 12
- Series 46008
